Evolution Powersports
Clutch Standard Weight Kit, for TAPP Primary
Clutch Standard Weight Kit, for TAPP Primary
Regular price
$20.00 USD
Regular price
Sale price
$20.00 USD
Shipping calculated at checkout.
Quantity
Fits these machines
✓ Confirmed fit- Make
- Can-AmPolaris
- Model
- Defender 1000Defender HD10Maverick X3 Turbo 120Maverick X3 Turbo 135Maverick X3 Turbo 154Maverick X3 Turbo R 172Maverick X3 Turbo RR 195Maverick X3 Turbo RR 200RZR Pro RRZR Pro XP 181RZR Turbo RRZR XP Turbo & Turbo S 168
+ 6 more
Maverick X3 TurboMaverick X3 Turbo RMaverick X3 Turbo RrRZR Pro XPRZR XP TurboRZR XP Turbo S - Years
- 2012–2026(selected years in this range)
- Type
- UTV
This part covers more than one machine. The lists above are combined, not paired — confirm your exact model and year before ordering, or text us the machine and we’ll confirm it.
Couldn't load pickup availability
Want to be sure it fits?Parts can vary by year, make, and model. If you already know it fits, go ahead and order with confidence — no call required. If you’d like a hand, reach out and we’ll gladly confirm fitment for you. Email sales@jkloffroad.com, call or text 579-509-2791.
DESCRIPTION
The weight in the arms of a TAPP primary can be adjusted in two ways: set screws in the arms, and washers on the roller thru bolt. Your clutch was shipped with a basic tuning kit. As with all other clutches, add weight to lower RPM, remove weight to raise RPM. Set screws in the arms affect the low-speed shift points more than the high speed and will reduce the max RPM. Weight on the roller axle bolt acts like tip weight in a conventional clutch, affecting the high-speed more than any other part of the curve. Adjust this as needed for your application.
STANDARD WEIGHT KIT INCLUDES:
Eight (8) 1/2 inch Allen screws
Four (4) 1-1/2" Roller Bolts
Four (4) 1-3/4" Roller Bolts
Four (4) 2" Roller Bolts
Four (4) Nylon Nuts
16 regular washers
IMPORTANT - As with all other adjustments, do this evenly and only in pairs across from each other, failure to do so will result in an imbalance of the clutch and possible failure.
Allen screws must be added in pairs opposite to one another. Allen screws are .500', weighing 2.7 grams. Adding two Allen screws will add 5.2 grams. Adding all eight Allen screws will add 20.8 grams.
| HARDWARE | DIMENSION | WEIGHT |
| Socket Head Screws (4) | 1.5" | 5.8 grams |
| Socket Head Screws (4) | 1.75" | 6.8 grams |
| Socket Head Screws (4) | 2.00" | 7.5 grams |
| Nylon Locknut (4) | 10-32 | 2.2 grams |
| Washer (16) | 0625 (1/16") | 1.2 grams |
